• New,
• Made in Germany,
• Product advantages and features:
• Large color display,
• Integrated printer,
• Simple operation,
• Modern and precise technological solutions,
• Fast and precise measurement,
• Refraction (A good initial subjective refraction value is essential. FAST REFRACTION MODE works well even with uncooperative patients)
• Keratometry KAI (kerato asymmetry index) and KRI (kerato regularity index) give a first indication of possible abnormalities on the cornea. This helps in evaluating the best vision correction or best-fitting contact lens),
• Topography (Various topographic maps help conduct eye exams, select contact lenses and educate patients),
• Tonometry (A very gentle blast of air created by a new generation of airflow technology means patients are more willing to accept the need for regular IOP measurement checks),
• Pachymetry (Correcting IOP by measuring central corneal thickness is essential for interpreting intraocular pressure),
• Dry eye analysis (Observe clients' eye health and assess long-term contact lens tolerance),
• Innovative solutions,
• Comfortable during the examination - takes a series of measurements in no time,
• Technical data:
• REFRACTOMETRY:
• Measurement range (spherical):
• Measurement range: -30.00 D to +25.00 D (at VD = 12.0 mm),
• Measuring range (cylindrical):
• Measurement range: 0 D to ± 12.50 D (at VD = 12.0 mm),
• Axial astigmatism (A):
• Measurement range: 0° to 180°,
• KERATOMETRY:
• Radius of curvature:
• Measurement range: 5.0 to 13.0 mm,
• Corneal astigmatic axis:
• Measurement range: 0 ° to 180 °,
• INTRAOCULAR PRESSURE MEASUREMENT:
• Measurement range: 1 mmHg to 60 mmHG (1 hPa to 80 hPa),
• PACHYMETRY MEASUREMENT:
• Measurement range: 300 μm to 800 μm,
• TOPOGRAPHIC MEASUREMENT:
• Corneal radius of curvature: 5.50 mm to 10.00 mm,
• Astigmatic axis of the cornea: 0° to 180°,
• AUXILIARY FUNCTION:
• Pupil distance: Measuring range: 20 mm to 85 mm,
• Corneal diameter and pupil diameter: Measuring range: 1.00 mm to 14.00 mm,
• Dry eye observation: Blink analysis, tear meniscus height, congestion, Meibom's glands,
• DATA MANAGEMENT:
• Internal database; Integrated SD card,
• Printer: Integrated thermal printer,
• Output data type: 3x USB 2.0, 1x LAN, 1x SD card slot, 1x WLAN,
• Export format: CSV, XML, JPG, PDF,
• Dimensions and electrical requirements:
• WDH dimensions: 312 x 491 x 450 mm,
• Weight: approx. 23.0 kg,
• Power supply: 100 V AC to 240 V AC,
• Frequency: 50/60 Hz,
• Power consumption: 110 VA,
• Has a current Technical Passport issued,
• Warranty 12 months,
